• Electrical Life: 2,000 operations min.
• Contact Resistance: 50mΩ max.
• Insulation Resistance: 100MΩ min
• Operation Temp:-20'C~ 70"C
• Operation Force:<9.8N max.
• Stroke: 2.0 mm
• Contact Rating:25mA@24VDC(switching);
100mA@50VDC(non-switching)
|
 |
   |
| Part Number | Electrical Life | Contact Resistance | Insulation Resistance | Operation Temp | Operation Force | Stroke | Contact Rating | PDF下載 |
|---|---|---|---|---|---|---|---|---|
| RDA | 2,000 operations min. | 50mΩ max. | 100MΩ min | -20℃~ 70℃ | ≤9.8N max. | 2.0 mm | 25mA@24VDC(switching);100mA@50VDC(non-switching) | 暫無 |
| RDE | 2,000 operations min. | 50mΩ max. | 100MΩ min | -20℃~ 70℃ | ≤9.8N max. | 2.0 mm | 25mA@24VDC(switching);100mA@50VDC(non-switching) | 暫無 |
| RDS | 2,000 operations min. | 50mΩ max. | 100MΩ min | -20℃~ 70℃ | ≤9.8N max. | 2.0 mm | 25mA@24VDC(switching);100mA@50VDC(non-switching) | 暫無 |
| RDP(L) | 2,000 operations min. | 50mΩ max. | 100MΩ min | -20℃~ 70℃ | ≤9.8N max. | 2.0 mm | 25mA@24VDC(switching);100mA@50VDC(non-switching) | 暫無 |
